YC SERIES 5HP MOTOR ELECTRIC AIR COMPRESSOR SINGLE PHASE MOTOR AC ELECTRIC MOTOR
Motor Data:
Rated frequency: 50 HZ or 60 HZ
| TYPE | OUTPUT | VOLTAGE (V) | CURRENT(A) | SPEED(R/MIN) | EFF(%) | POWER FACTOR |
IST/IN | TM.AX/TN | |
| HP | KW | ||||||||
| YC-80A-2 | 0.5 | 0.37 | 220 | 3.7 | 2880 | 62 | 0.73 | 6.5 | 1.8 |
| YC-80B-2 | 0.75 | 0.55 | 220 | 5.3 | 2880 | 65 | 0.73 | 6.5 | 1.8 |
| YC-80C-2 | 1 | 0.75 | 220 | 6.7 | 2880 | 68 | 0.75 | 6.5 | 1.8 |
| YC-90S-2 | 1.5 | 1.1 | 220 | 9.1 | 2880 | 71 | 0.77 | 7 | 1.8 |
| YC-90L-2 | 2 | 1.5 | 220 | 12.1 | 2900 | 72 | 0.78 | 7 | 1.8 |
| YC-100L-2 | 3 | 2.2 | 220 | 17.1 | 2900 | 74 | 0.79 | 7 | 1.8 |
| YC-112M1-2 | 4 | 3 | 220 | 21.4 | 2900 | 76 | 0.84 | 7 | 1.8 |
| YC-112M2-2 | 8 | 3.7 | 220 | 24.8 | 2900 | 79 | 0.86 | 7 | 1.8 |
| YC-80A-4 | 1/3 | 0.25 | 220 | 3.4 | 1450 | 56 | 0.6 | 6 | 1.8 |
| YC-80B-4 | 0.5 | 0.37 | 220 | 4.5 | 1450 | 60 | 0.62 | 6 | 1.8 |
| YC-80C-4 | 0.75 | 0.55 | 220 | 6 | 1450 | 64 | 0.65 | 6 | 1.8 |
| YC-90S-4 | 1 | 0.75 | 220 | 7.7 | 1450 | 67 | 0.66 | 6.5 | 1.8 |
| YC-90L-4 | 1.5 | 1.1 | 220 | 10.5 | 1450 | 70 | 0.68 | 6.5 | 1.8 |
| YC-100L-4 | 2 | 1.5 | 220 | 13.5 | 1450 | 72 | 0.7 | 6.5 | 1.8 |
| YC-112M-4 | 3 | 2.2 | 220 | 19.3 | 1450 | 72 | 0.72 | 6.5 | 1.8 |
| YC-132SA-4 | 4 | 3 | 220 | 25.2 | 1450 | 74 | 0.73 | 6.5 | 1.8 |
| YC-132SB-4 | 5 | 3.7 | 220 | 30 | 1450 | 75 | 0.74 | 6.5 | 1.8 |
| YC-132M-4 | 7.5 | 5.5 | 220 | 32.5 | 1450 | 81 | 0.95 | 6.5 | 1.8 |
YC SERIES 5HP MOTOR ELECTRIC AIR COMPRESSOR SINGLE PHASE MOTOR AC ELECTRIC MOTOR
♦OPERATING CONDITIONS
♣Ambient temperature:-15°c<Θ<40°c
♣Altitude:not exceed 1000m
♣Rated voltage:220v
♣Rated frequency:50Hz/60Hz
♣Dyty:S1(continuous)
♣Insulation class:B/F
♣Protection class:IP44/IP54
♣Cooling method:IC0141
EXPLODEDVIEW:
1. who are we?
We are based in Zhejiang, China, start from 2001,sell to South Asia(30.00%),South America(20.00%),Western Europe(20.00%),Southeast Asia(20.00%),Eastern Asia(5.00%),Africa(5.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Electric Motor, Worm Reducer, AC Gear Motor
4. why should you buy from us not from other suppliers?
The company manufacture the motor and worm reducer together.It is convenient to the customer. The company have more than 10 years' experience to produce electirc motor,we have strictly quality control system.
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,Express Delivery;
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C;
Language Spoken:English,Chinese
